Infineon TDA21240AUMA1: A 40 V Automotive Dual-Channel Smart High-Side Switch

The increasing complexity of automotive electronic systems demands robust, intelligent, and highly integrated power management solutions. The Infineon TDA21240AUMA1 stands out as a premier component designed to meet these stringent requirements. This device is a dual-channel smart high-side switch fabricated using Infineon's proprietary SPOC (Smart Power and Octal) technology, engineered specifically for 40 V automotive applications.

At its core, the TDA21240AUMA1 is designed to drive resistive or inductive loads—such as solenoids, valves, motors, and lamps—with exceptional reliability. Each of its two independent channels can handle a continuous current of up to 2.5 A, making it suitable for a wide range of medium-power functions within the vehicle's body control modules, powertrain systems, and convenience features.

A key attribute of this switch is its "smart" functionality, which provides comprehensive diagnostic and protection features crucial for automotive safety and reliability. It offers precise load current feedback to the microcontroller, enabling real-time monitoring and detection of fault conditions. These include short-circuit protection, over-load protection, over-temperature shutdown, and over-voltage clamp. The device also features reverse battery protection up to -40 V, safeguarding the system from incorrect jumper cable connections during maintenance. In the event of a fault, the device enters a safe state and reports the condition back to the control unit, ensuring system integrity and facilitating easier diagnostics.

Furthermore, the TDA21240AUMA1 is designed for the challenging automotive environment. It boasts a high level of electromagnetic compatibility (EMC) and is AEC-Q100 qualified, guaranteeing its performance across the extreme temperature ranges and harsh conditions typical of automotive applications. Its compact and thermally efficient PG-DSO-14 package makes it an ideal choice for space-constrained designs.

ICGOOFind: The Infineon TDA21240AUMA1 is an advanced, highly integrated power switch that delivers robust performance, intelligent diagnostics, and comprehensive protection. It simplifies design, enhances system reliability, and is a cornerstone for developing efficient and safe automotive electronic systems.

Keywords: Automotive Grade, Dual-Channel, Smart High-Side Switch, Diagnostic Features, AEC-Q100 Qualified.
